Rheinhutte : RCNKu

Standardised chemical pump in plastic

The RCNKu is a horizontal, single-stage, end-suction, top-discharge centrifugal pump used for handling chemically aggressive and/or inflammable liquids within the wide field of chemical processing and environmental technology.

The RCNKu with closed impeller is foreseen for clean liquids and fluids with a small content of solids.

The pump is equipped with the i-ALERT^®2 sensor as standard. This monitors vibrations and temperature. If preset limit values are exceeded, LEDs in the sensor light up. All measured values can be retrieved via an app of the Ai Platform. This means that necessary measures can be taken in good time before the pump fails.

Specifications

• Head: 100m
• Capacity: 2.500 m3/h
• Temperature: -40 °C to 190 °C
• Size: DN 80 - 400


Applications

• Chlor-Alkali Electrolysis
• Sulphuric acid
• Steel and Stainless steel pickles
• Titanium dioxide
• Phosphoric acid
• Sea water
• Waste incineration (flue gas cleaning)
• Scrubber
• Waste water
• Hydrochlorid acid

Materials

• Polyvinyliden-Fluoride PVDF
• Polytetrafluorethylene PTFE
• Polypropylene PP
• Polyethylen PE 1000 UHMW-PE
• Polyethylene PE 1000 R
